Many have purchased this flight controller on Banggood or else where but have issues Flashing and configuring the OSD as the description say that you can do this from the USB.
I got in contact with Diatone that where very fast to help me out.
This is the solution to Flash and configure the OSD on the Diatone NAZE32(B) REV6 Plus 6DF & OSD Flight Controller.
You need a USB Linker. (http://www.banggood.com/FTDI-Basic-Program-Downloader-USB-TTL-3_3-5V-FT232-For-Arduino-p-988937.html)
Second Connect the power to the OSD Power pads to give the OSD power.
From the USB linker … Read More
This time i have built another small 210mm quad. What makes this one interesting is that the center of gravity is very low due to the fact that all components are under the quad instead of on top together with battery and other stuff. But the frame has its problems to!
This time the build post is a bit shorter but with more images.
Naze32 Rev6 10Dof
EMAX Cooling 2206 1900kv (will be interesting to see if i have to replace them with … Read More
As soon as it’s built i will publish a build-log here and let you know my pros and cons with the frame.
DYS MX20A ESCs
EMAX Cooling 2206 1900kv
What do you think about the setup, are the ESC’s to week, should i go 30A?
Building this quad was with both happiness and frustration. By the time i was finished building this quad i had mounted and unmounted the stacking of the PDB, NAze32 and the OSD probably 30 times, i will let you know why.
Components used in this build
Lantian LT 210 frame
Naze32 10 dof Rev6
brOSD (That you can stack on the Naze32)
Matek 5 in 1 PDB (that you can stack)
TS5823S 40CH 5.8G 200MW AV Transmitter
Sony CCD 600TVL FPV Cam
DYS MX20A BLHeli ESC
Emax 2204 … Read More
Just sharing a pic of my next project. Just waiting for a power distribution board that I can stack with the Naze32 and the OSD.
Lantian LT 210 (5mm)
Emax 2204 2300kv
Dys mx20A ESC with oneshot
And FPV stuff etc… 😄
Build blog post will come very soon.
The flight was in 15m/s winds and snow on the ground. Made it with just a broken landing gear, those sledge formed gears don’t do very good in wet snow 😉 see pic…
To my next project i wanted a frame where i can fit my ESCs in the frame compared to the usual placement on the arms. I looked at the GT-250 250mm from Banggood but didn’t like that it was made of Fiberglass. Fiberglass is not as hard and lightweight as carbon fiber and if its stored in a humid climate it can start bend over time. But to my luck i found the exact same model made in carbon fiber on Aliexpress, … Read More
I have tried to find information regarding the CC3D modes but the Wiki is broken and finally i found a video describing the modes shortly. Ill dokument whet i learned here.
… Read More
Just got one of my new lipos and the t-plug on it didn’t connect on any of my models. Tried to bend and scratch the plates in the plug but didn’t help. I removed the shrink tube to look at the connections to the cables and they where both fine.
Replaced the plug and the lipo was working.
Super strange as the construction is pretty simple!
